CINO 6890 條形碼掃描器

MBC-6890(無線掃描器)
光源 波長630nm 紅色LED
接收裝置 3648 像素線形影象元件
讀取距離 LR -up to 30 CM HD -up to 25CM
無線通訊距離 class one: 100米,clss two:30米
取寬度 0-14cm
掃描速度 300scan/sec
黑白對比PCS值0.30
掃描景深 LR - Typical 4 mil, 3.5 mil 可讀
掃描景深 HD- Typical 3 mil, 2.8 mil 可讀
讀取傾斜角度 上下仰角+/-45度
左右傾角角度 左右傾角+/-45度
工作電流 150mA
低耗電待機模式 小于100uA
工作溫度 0-50℃
儲存溫度 -20/60℃
抗光干擾 0-50,000Lux
ESD參數 承受8KV靜電不影響性能
重量 200克(不含纜線)
通過認證 FCC，CE，EMC

MBC-6890 wireless Long Range Linear Imager has been designed to replace traditional laser bar code scanner with lower cost. Equipped with the new generation light intensifier and optical design, all MBC-6890 series gives sharply visible high intensity aiming line and distance bar code capture even from 12" away.
With more than 200 sophisticate programmable parameters and the Universal Interface feature, one single unit of the MBC-6890 can work with more than 60 different host machines through various user-replaceable interface cable converters to meet any requirements. Unqiue NeuroFuzzy decoding engine drives MBC-6890 to perform fast and accurate scanning, even for the +/- 200% distorted bar code images. Its superior readability gives great productivity to all data collection application.

Working with the world' sonly Windows utility, MBC-6890 PowerTool,all jobs of configuration setup, parameter download and upload, program upgrade, and on-line diagnosis could be done with ease at your fingertip.
